Features:
Action type: double acting, single rod. Bore: 20mm, stroke: 25mm.
Made of premium quality material, high hardness and durable, ensure long service life.
Strong impact resistance, more stable when working, more safe when operating.
Excellent sealing ring, the air cylinder is of high efficiency to prevent piston leakage.
Widely applied to the automatic equipment in light industry, chemical industry, textile industry, electronic industry.
Specifications:
Material: Stainless Steel + Steel
Type: MA 16 * 25/ 50/ 75/ 100/ 150/ 175, MA 20 * 25/ 50/ 75/ 100/ 150/ 175, MA 25 * 25/ 50/ 75/ 100/ 150/ 175, MAL 40 * 25/ 50/ 75/ 100 (Optional)
Port Size:
MA 16 Series: M5 * 0.8
MA 20 Series & MA 25 Series: PT 1/8''
MAL 40 Series: PT 1/4''
Action Type: Double Acting
Working Pressure Range: 1.5~10kgf/ cm2 (0.15~1.0MPa)
Proof Pressure: 15kgf/ cm2 (1.47MPa)
Fixed Type: Basic Type
Working Speed Range: 30-800mm/ s
Working Temperature: 0-70℃
Working Medium: Air
Package List:
1 * Pneumatic Cylinder
